XL1509-ADJE1 SMD IC A DC to DC Converter SOIC8 XLSEMI XL1509-ADJE1

Product Overview:

A 2A, 150KHz fixed-frequency PWM buck (step-down) DC/DC converter integrated circuit designed for applications requiring high efficiency and load driving capability, such as LCD monitors, modems, and networking equipment.

Core Specifications:

Manufacturer: XLSEMI

Package Type: SOP8L

Function: Buck DC to DC Converter

Input Voltage Range: 4.5V to 40V

Output Current: Up to 2A

Features:

• Fixed 150KHz switching frequency

• Output adjustable from 1.23V to 37V (also available in fixed 3.3V, 5V, 12V versions)

• Internal current limit and thermal shutdown functions

• TTL shutdown capability via ON/OFF pin

• Excellent line and load regulation

Applications:

• LCD Monitors and TVs

• Digital Photo Frames

• Set-top Boxes

• ADSL Modems

• Telecom/Networking Equipment
