ULN2804 IC Darlington Transistor Array DIP-18 ULN2804

Product Overview

The ULN2801A is an integrated circuit containing eight independent Darlington transistors with common emitters, designed to interface standard logic families with higher power loads. It includes integral suppression diodes, making it ideal for driving inductive loads such as relays, solenoids, and stepper motors. The device supports paralleling outputs for higher current capability and features a convenient input-opposite-output pinout to simplify PCB layout.

Core Specifications

Manufacturer: STMicroelectronics

 Function: Eight Darlington Array
