UCD4081 IC AND GATE UTC DIP14 UCD4081

Product Overview: The CD4071BC consists of four independent 2-input OR gates constructed with N- and P-channel enhancement mode complementary MOS (CMOS) transistors. It features buffered outputs which improve transfer characteristics by providing very high gain, and all inputs are protected against static discharge with diodes to VDD and VSS. Typical applications cover logic circuit design, signal gating, and low-power TTL interfacing.

Core Specifications:

• Manufacturer: Fairchild Semiconductor Corporation

• Package Type: 14-lead SOIC (M14A) and 14-lead plastic DIP (N14A) packages

• Function: Quad 2-input OR buffered B-series gate offering symmetrical output characteristics and low power consumption over 5V, 10V, and 15V parametric ratings
