TDA2030AL IC UTC 2030 TO220B audio amplifier TDA2030AL

The TDA2030AL is a monolithic integrated circuit designed as a low-frequency Class-AB audio power amplifier. It is capable of providing high output current with very low harmonic and cross-over distortion, making it suitable for Hi-Fi audio systems.

Core Specifications

•

  Manufacturer: Unisonic Technologies Company (UTC)

•

  Package Types: Available in TO-220-5 and TO-220B packages.

•

  Function: 18W Hi-Fi Audio Amplifier and 35W Driver.

•

  Supply Voltage: Optimized for applications with a maximum supply voltage ($V_s$) of up to 44V.

•

  Protection: Includes an integrated short-circuit protection system that limits dissipated power to maintain the output transistors within their safe operating area, along with a thermal shutdown system.
