LM2931 IC LDO Regulator DIP-4 LM2931

Product Overview

The LM2931-N is a positive voltage regulator designed for applications requiring very low quiescent current and protection against harsh electrical environments. It features a quiescent current of 1 mA or less when supplying 10 mA loads, making it ideal for standby power systems, memory standby circuits, and low-power processor supplies. Originally designed for automotive use, the device includes robust protection against reverse battery installations, load dumps (up to 60 V), and reverse transients.

Core Specifications

• Manufacturer: Texas Instruments

• Function: Low Dropout (LDO) Positive Voltage Regulator

• Output Current: In excess of 100 mA

• Dropout Voltage: Less than 0.6 V (input-output differential)

• Quiescent Current: 1 mA or less (at 10 mA load)

• Protection Features: Reverse battery protection, 60 V load dump protection, -50 V reverse transient protection, internal thermal overload protection, and short-circuit protection

• Available Packages: TO-220, TO-92, TO-263, SOIC-8
