LD1117 IC 3.3V – LDO Regulator DIP-3 LD1117

Product Overview: A low-dropout (LDO) positive voltage regulator capable of providing up to 800 mA of output current, available in both fixed and adjustable output voltage versions.

Core Specifications:

• Manufacturer: STMicroelectronics

• Component Type: Low-Dropout (LDO) Positive Voltage Regulator

• Dropout Voltage: 1 V (typical)

• Maximum Output Current: 800 mA

• Fixed Output Voltage Options: 1.2 V, 1.8 V, 2.5 V, 3.3 V, 5.0 V

• Adjustable Version: Yes (Vref = 1.25 V)

• Integrated Protection: Internal current and thermal limiting

• Package Options: SOT-223, DPAK, SO-8, TO-220
