IRFP2401 MOSFET TO-247 VISHAY IRFP2401

Product Overview:

A through-hole N-Channel power MOSFET engineered for high-power, high-speed switching applications. Utilizing advanced planar technology, this device provides an optimal combination of fast switching capability, ruggedized device design, low on-resistance ($R_{DS(on)}$), and cost-effectiveness.

Packaged in a robust TO-247 enclosure, it features an isolated central mounting hole and greater creepage distances between pins, making it highly preferred for commercial-industrial applications where higher power levels preclude the use of standard TO-220 devices. It features a dynamic $dv/dt$ rating and full repetitive avalanche characterization to ensure stable, reliable performance under harsh electrical stresses. This versatile component is widely used in power management environments such as switch-mode power supplies (SMPS), DC-to-DC converters, motor control drivers, and extensively in the output stages of high-power audio amplifiers due to its ease of paralleling.

Core Specifications:

• Manufacturer: Vishay Siliconix

• Package Type: TO-247AC / TO-247

• Function: N-Channel Power MOSFET

• Maximum Drain-Source Voltage: 200V

• Continuous Drain Current: 20A (at 25°C) / 12A (at 100°C)

• Specific Variant: IRFP240 / IRFP240PBF
