IL386 IC Audio Amplifier IKSEMI DIP8 IL386

Product Overview: The IL386 by IK Semiconductor is a low-voltage audio power amplifier designed specifically for consumer applications, making it highly suitable for battery-operated devices. The device features ground-referenced inputs and an output that automatically biases itself to one-half of the supply voltage. With an exceptionally low quiescent power drain of just 24 mW when running on a 6-V supply, it ensures efficient energy use. The internal voltage gain is default-set to 20 (26 dB) to minimize external component count. However, by connecting an external resistor and capacitor between pins 1 and 8, the voltage gain can be adjusted to any value up to 200 (46 dB).

Core Specifications:

• Manufacturer: IK Semiconductor
