D882 transistor TO126 CDIL CSD882P NPN 30V 3A transistor 882 CDIL D882

Product Overview:

A through-hole NPN silicon epitaxial planar bipolar junction transistor housed in a TO-126 plastic package. Designed for medium-power applications requiring high current handling at relatively low voltages, it features a low saturation voltage and high linear current gain. It is widely used in voltage regulators, audio power amplifier output stages, relay drivers, and DC-to-DC converters. It frequently serves as the complementary NPN pair to the B772 (or CSB772) PNP transistor.

Core Specifications:

• Manufacturer: CDIL (Continental Device India Limited)

• Package Type: TO-126

• Function: NPN Medium Power Transistor

• Maximum Collector-Emitter Voltage ($V_{CEO}$): 30V

• Maximum Continuous Collector Current ($I_C$): 3A (Peak current $I_{CP} = 7\text{A}$)

• Maximum Collector Power Dissipation ($P_C$): 12.5W (with suitable heatsink at $T_C = 25^\circ\text{C}$)

• Common Marking Code: D882 / CSD882P
