SP010N01BGHTO SMD MOSFET TOLL-8L Siliup 100V 370A 10N01 SP010N01BGHTO

Product Overview

A surface-mount N-Channel power MOSFET designed using advanced split-gate trench technology. It offers extremely high current density, fast switching speeds, and ultra-low on-resistance ($R_{DS(on)}$) in a thermally enhanced package, making it highly efficient for high-frequency hard-switched circuits, power management, and pulse-width modulation (PWM) applications.

Core Specifications

• Manufacturer: Siliup (Siliup Semiconductor)

• Package Type: TOLL-8L (TO-Leadless 8-Lead)

• Function: SMD MOSFET (N-Channel)

• Voltage Rating: 100V

• Current Rating: 370A

• Power Dissipation: 410W

• Static On-Resistance ($R_{DS(on)}$): ~1.1 mΩ (typical @ $V_{GS}$ = 10V)

• Marking Code: 10N01

• Part Number: SP010N01BGHTO
