CD4070BM SMD IC NOR GATE SOIC14 TI CD4070BM

Product Overview:

A surface-mount, quad exclusive-OR (XOR) gate integrated circuit designed for medium-speed logic applications. It provides logical comparison functions where the output is high only when the two inputs are at different logic levels, making it essential for digital arithmetic and data comparison circuits.

Core Specifications:

Manufacturer: Texas Instruments

Package Type: Available in various packages including PDIP, CERDIP, SOIC, SOP, and TSSOP

Function: Quad Exclusive-OR Gate

Input Channels: 4 Independent 2-Input XOR Gates

Control Interface: Direct Logic Input

Features:

• High-voltage type (20V rating)


• Buffered inputs and outputs for stable signal integrity

• Standardized symmetrical output characteristics

• Wide operating temperature range: -55°C to +125°C

Applications:

• Digital arithmetic (e.g., full-adder and half-adder circuits)

• Parity generation and checking

• Magnitude comparators

• Phase-locked loop (PLL) frequency comparison

• Code conversion and digital logic design
