CD4052 IC 8-Channel Analog Multiplexer/Demultiplexer TI DIP-16 CD4052

Product Overview

The CD4051BC is a digitally controlled, single 8-channel analog multiplexer and demultiplexer. Operating as a bidirectional analog switch, it features a low "ON" impedance and extremely low "OFF" leakage currents.

The chip utilizes three binary control inputs (A, B, and C) to select and turn "ON" 1 of 8 channels, connecting that specific input to the common output. Additionally, it features an active-HIGH Inhibit input terminal that overrides the binary controls, turning all channels "OFF" simultaneously when a logical "1" is applied. It is highly efficient, maintaining very low quiescent power dissipation across its entire supply voltage range regardless of the logic state of its control signals.

Core Specifications

• Manufacturer: Fairchild Semiconductor

• Function: Single 8-Channel Analog Multiplexer / Demultiplexer
