BC107 Transistor NPN Transistor 107 Central Semiconductor BC107

Product Overview

The BC107 is a general-purpose, low-noise NPN bipolar junction transistor (BJT) housed in a robust TO-18 metal can package. Manufactured by Central Semiconductor, it is designed for small-signal amplification and switching applications. Its metal casing provides excellent thermal stability and electromagnetic shielding, making it a reliable choice for sensitive audio circuits, low-noise input stages, and signal processing tasks in industrial and consumer electronics.

Core Specifications

• Manufacturer: Central Semiconductor

• Package Type: TO-18 (Metal Can)

• Component Type: NPN Silicon Transistor

• Collector-Emitter Voltage ($V_{CEO}$): 45V

• Collector-Base Voltage ($V_{CBO}$): 50V

• Emitter-Base Voltage ($V_{EBO}$): 6V

• Continuous Collector Current ($I_C$): 200mA

• Power Dissipation ($P_{tot}$): 600mW (at $T_A = 25^\circ C$)

• DC Current Gain ($h_{FE}$): 110 to 450 (varies by specific gain bin)

• Transition Frequency ($f_T$): 150 MHz (Typical)

• Part Number: BC107
