ADXL335 3-Axis Accelerometer Module ADXL335
ADXL335 3-Axis Accelerometer Module ADXL335
SKU:ADXL335
100 in stock
Couldn't load pickup availability
DESCRIPTION
This is an updated triple-axis accelerometer from adafruit which now have an on-board 3.3V regulator - making it a perfect choice for interfacing with a 5V microcontroller such as the Arduino. This breakout comes with 3 analog outputs for X, Y and Z axis measurements on a 0.75"x0.75" breakout board. The ADXL335 is the latest and greatest from Analog Devices, known for their exceptional quality MEMS devices. The VCC takes up to 5V in and regulates it to 3.3V with an output pin. The analog outputs are ratiometric: that means that 0g measurement output is always at half of the 3.3V output (1.65V), -3g is at 0v and 3g is at 3.3V with full scaling in between .Two 2mm (0.08") mounting holes for easy attachment.The XYZ filter capacitors are 0.1uF for a 50 Hz bandwidth
The ADXL 335, 3-axis accelerometer, now has an onboard 3.3V regulator - making it a perfect sensor module for Arduino, Raspberry Pi, and similar Microcontrollers. This breakout comes with 3 analog outputs for X, Y and Z axis breakout board. The ADXL335 is the latest and greatest from Analog Devices, known for their exceptional quality MEMS devices and applications in Robotics is now available at Tomson Electronics, Kochi, Kerala, India.
The VCC takes up to 5V in and regulates it to 3.3V with an output pin.
The analog outputs are ratiometric: that means that 0g measurement output is always at half of the 3.3V output (1.65V), -3g is at 0v and 3g is at 3.3V with full scaling in between.Fully assembled and tested. The XYZ filter capacitors are 0.1uF for a 50 Hz bandwidth.
