74LS26 IC Quad 2-Input NOR Gate DIP-14 74LS26

Product Overview

The 74LS26 is a digital logic device containing four independent 2-input NAND gates. These gates are specifically designed with high-voltage, open-collector outputs, allowing them to interface with low-threshold-voltage MOS logic circuits or other 12-volt systems, while the $V_{CC}$ terminal operates at a standard 5-volt level.

Core Specifications

• Manufacturer: Texas Instruments

• Package Type: Available in Plastic Small Outline (SOIC), Plastic Dual-In-Line (PDIP), and Ceramic Chip Carrier (FK)

• Function: Quadruple 2-input high-voltage interface positive-NAND gates with open-collector outputs
