74LS150 IC 16-to-1 Data Selector/Multiplexer DIP-24 74LS150

Product Overview

The DM74150 is a 16-line to 1-line data selector/multiplexer. It features full on-chip decoding to select a single data source from sixteen distinct inputs. An active-LOW strobe input is provided to enable or disable the chip; when the strobe is driven HIGH, the device is disabled, forcing the output to a HIGH logic state regardless of other inputs.

Core Specifications

Manufacturer: Fairchild Semiconductor

Function: 16-Input Data Selector / Multiplexer
