74LS133 IC 13-Input NAND Gate DIP-14 74LS133

Product Overview

The 74LS133 is a digital logic device containing a single 13-input NAND gate. It operates using standard TTL (Transistor-Transistor Logic) voltage levels and performs the positive-NAND logic function. Due to its high number of inputs, it is primarily used in complex address decoding or large-scale combinatorial logic circuits where a high fan-in is required.

Core Specifications

• Manufacturer: Motorola

• Package Type: Available in various packages including Ceramic (J), Plastic (N), and Small-Outline (D) packages.

• Function: Single 13-input NAND gate.
