74LS13 IC Dual 4-Input NAND Schmitt Trigger DIP-14 74LS13

Product Overview

The SN74LS138 is a 3-line to 8-line decoder/demultiplexer, utilizing Schottky-clamped TTL MSI circuitry to achieve high-speed performance. It is specifically designed for high-performance memory decoding and data-routing applications where minimizing propagation delay is critical. The device features three enable inputs (two active-low and one active-high) which facilitate easy cascading and reduce the need for external logic gates.

Core Specifications

Manufacturer: Texas Instruments

Function: 3-Line to 8-Line Decoder/Demultiplexer
