74LS123 IC dual retriggerable monostable multivibrator DIP-16 74LS123

Product Overview

The 74LS122 is a retriggerable monostable multivibrator that provides precise control over output pulse duration. The basic pulse width is programmed using external resistance and capacitance; notably, the LS122 includes an internal timing resistor, allowing operation using only an external capacitor. The pulse duration can be extended by retriggering the gated inputs (A and B) or terminated prematurely using the overriding clear input.

Core Specifications

• Manufacturer: Motorola

• Package Type: Ceramic (J Suffix) and other standard package options

• Function: Retriggerable monostable multivibrator
