74LS00 IC quad 2-input NAND gate DIP-14 74LS00

Product Overview

The 74LS00 is a digital logic device containing four independent gates, each of which performs the logic NAND function. This device is a fundamental building block in digital electronics, providing a standard TTL (Transistor-Transistor Logic) output.

Core Specifications

• Manufacturer: Fairchild Semiconductor

• Package Type: Available in 14-Lead Small Outline Integrated Circuit (SOIC), 14-Lead Small Outline Package (SOP), and 14-Lead Plastic Dual-In-Line Package (PDIP)

• Function: Quad 2-input NAND gate
