74HC541 DRIVER IC 74HC541D

Product Overview

A three-state output octal buffer and line/bus transceiver driver integrated circuit utilizing high-speed CMOS technology. It features an efficient output control design where the three-state outputs are managed jointly by dual active-low output enable inputs (OE1 and OE2). When both enable inputs are driven low, the outputs track the logic states of their corresponding inputs; if either enable input is driven high, all outputs enter a high-impedance state to prevent bus contention.

Core Specifications

• Manufacturer: GR

• Package Type: 20-Pin Formats including PDIP20 (74HC541PD), SOP20 (74HC541S), SSOP20 (74HC541SS), TSSOP20 (74HC541TS), and SOIC20 (74HC541SO)

• Function: Octal Buffer and Line/Bus Transceiver Driver with 3-State Outputs

• Input Channels: 8-Channel Individual Data Inputs (A1 to A8)

• Control Interface: Dual Active-Low Output Enable Pins (OE1 and OE2)
