74HC03 IC Quad 2-Input NAND Gate with Open-Drain Outputs 74HC03N-DIP-14

Product Overview: The 74HC03 is a high-speed CMOS quad 2-input NAND gate integrated circuit. A key feature of this device is its open-drain output configuration. Unlike standard NAND gates that provide both active High and active Low drive, these open-drain outputs act like a switch to ground, requiring an external pull-up resistor to pull the output to a logic High state.

Core Specifications:

• Manufacturer: HuaGuan Semiconductor (HHGSEMİ)

• Package Types: DIP-14, SOP-14, TSSOP-14

• Function: Quadruple 2-Input NAND Gate with Open-Drain Outputs
