47uF 63V Electrolytic Capacitor samwha 47uF 63V

Product Overview

The Samwha 47µF 63V electrolytic capacitor is a high-voltage, polarized radial through-hole component. Typically part of Samwha’s general-purpose SD or SM series, this capacitor is engineered for analog signal coupling, DC decoupling, and intermediate power smoothing.

With its 63V rating, it is particularly useful in circuits that require higher voltage tolerance than standard low-voltage logic rails, such as pre-amplifier audio stages, control logic circuits, and secondary power supply filtering in medium-voltage applications.

Core Specifications

• Manufacturer: Samwha Electric Co., Ltd.

• Capacitance: 47µF (Microfarads)

• Voltage Rating: 63V DC

• Tolerance: ±20%

• Temperature Rating: 85°C Max (Standard SD variant)

• Mounting Style: Radial Leaded Through-Hole (THT)

• Physical Dimensions: Typically 6.3mm to 8mm Diameter x 11mm Height

• Lead Pitch (Spacing): 2.5mm to 3.5mm
