40 Pin ZIF Test Dip IC Socket Connector

Product Overview:
A 40-pin Zero Insertion Force (ZIF) socket designed for the safe insertion and removal of Dual In-line Package (DIP) integrated circuits without damaging the component leads.

Core Specifications:
* Manufacturer: Adafruit Industries
* Component Type: ZIF (Zero Insertion Force) Socket
* Pin Configuration: 40-pin (2 x 20)
* Supported Chip Width: 0.3" to 0.6" (DIP)
* Pin Spacing: 0.6" pitch
* Pin Length: 2.8 mm (0.11")
* Overall Dimensions: 23 mm x 66 mm x 12 mm (0.9" x 2.6" x 0.46") excluding lever and pins
* Contact Finish: Gold-plated
* Mounting Style: Through-hole (Breadboard compatible)
