4 PIN Tactile Push Button MICRO SWITCH 6X6X9.5mm HEIGHT 9.5MM

Product Specifications

• Product Name: Right-Angle Tactile Push Button Micro Switch 6×6×9.5mm

• Part Number:

• Brand:

• Type: Right-Angle Tactile Push Button

• Insulation Resistance: >100MΩ

• Operating Life: Up to 1 Million Operations

• Operating Force: 1.6–2.5N

• Travel: 0.25mm

• Operating Temperature: -35°C to +85°C

• Color: Black / White

• Dimensions: 6 × 6 × 9.5mm

• Notch Height: H1 8.3mm / H2 9.5mm

• Notch Diameter: 3.1mm
