330uF 25V Electrolytic Capacitor 85C 20% KELTRON 330uF 25V

Product Overview

The KELTRON 330uF (25V) Radial Electrolytic Capacitor is a miniature, polarized aluminum through-hole component built for lower-voltage electronic pathways. Belonging to Keltron's standard SA series, this device delivers reliable DC voltage smoothing, signal decoupling, and noise bypassing.

Its 85°C temperature rating and compact size make it highly suitable for microcontroller power lines, consumer-grade desktop electronics, signal processing modules, and DIY embedded circuits.

Core Specifications

• Manufacturer: Keltron

• Capacitance: 330µF

• Voltage Rating: 25V DC

• Tolerance: ±20%

• Temperature Rating: 85°C Max

• Series: SA Series (Standard Part Code: SA3311EMBBB0)

• Mounting Style: Radial Leaded Through-Hole (THT)

• Physical Dimensions: 8mm Diameter x 12.5mm Height

• Lead Pitch (Spacing): 3.5mm

• Pin Hole Diameter: 0.6mm
