24C64N SMD IC EEPROM SOP8

Product Overview:
A 64-Kb I2C serial EEPROM integrated circuit supporting Standard, Fast, and Fast-Plus protocols, organized internally as 256 pages of 32 bytes.

Core Specifications:
* Manufacturer: onsemi
* Component Type: EEPROM (Electrically Erasable Programmable Read-Only Memory)
* Memory Capacity: 64-Kb
* Communication Interface: I2C Serial (up to 1 MHz)
* Supply Voltage Range: 1.7 V to 5.5 V
* Page Write Buffer: 32 Bytes
* Maximum Write Time: 4 ms
* Reliability: 1,000,000 Program/Erase Cycles, 100-Year Data Retention
* Environmental Grade: Automotive AEC-Q100 Grade 1 (-40°C to +125°C)
* Protection Features: Hardware Write Protection for Entire Memory
