1000uF 10V Electrolytic Capacitor JWCO 105C 8x12mm 1000uF 10V

Product Overview

The JWCO 1000µF 10V electrolytic capacitor is a high-capacitance, polarized radial through-hole component. Featuring an upgraded 105°C thermal rating, this capacitor is designed for bulk energy storage, secondary DC voltage smoothing, and ripple current filtering in space-constrained applications.

With its compact 8x12mm form factor, it is an ideal choice for low-voltage power supply lines, such as those powering microcontrollers, digital signal processors (DSPs), and peripheral circuitry on modern PCBs.

Core Specifications

• Manufacturer: JWCO (Jiaweicheng Electronics)

• Capacitance: 1000µF (Microfarads)

• Voltage Rating: 10V DC

• Tolerance: ±20%

• Temperature Rating: Up to 105°C (High-Temperature Grade)

• Mounting Style: Radial Leaded Through-Hole (THT)

• Physical Dimensions: 8mm Diameter x 12mm Height

• Lead Pitch (Spacing): 3.5mm
